Doosan DX225LCA tracked excavator
≈ SGD 37,760
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+86 183 575...
Show
+86 183 5759 0723
China
30,125 kg
Digging depth
7.27 m
China
21,800 kg
China
21,800 kg
Digging depth
6,592 m
China, Shanghai
30,000 kg
Digging depth
7.275 m
China, Hefei City, Anhui Province
30,000 kg
Digging depth
7.275 m
China, Hefei City, Anhui Province
21,800 kg
Digging depth
6,592 m
China, Shanghai
21,800 kg
Digging depth
6,592 m
China, Shanghai
China, Shanghai
21,800 kg
Digging depth
6.6 m
China, Shanghai
22,500 kg
China
21,800 kg
Digging depth
6,630 m
China, Shanghai
30,000 kg
Digging depth
7.36 m
China, Shanghai
31,000 kg
Digging depth
7.5 m
China
30,000 kg
Digging depth
7.2 m
China
6.63 m
China
30,000 kg
Digging depth
7.275 m
China, Shanghai
21,800 kg
Digging depth
6.592 m
China
22,500 kg
China
China
30,000 kg
China
Operating Weight: ~22,500 kg
Engine Power: 118 kW (158 HP) @ 1,900 rpm (Tier 4 Final / EU Stage V compliant)
Bucket Capacity: 0.8–1.2 m³ (standard ~1.0 m³)
Fuel Tank Capacity: 400 L
2. Engine
Model: Doosan DL06 (turbocharged, intercooled)
Displacement: 6.7 L
Cylinders: 6
Emission Standard: Tier 4 Final / EU Stage V (with SCR & DPF)
3. Performance
Max Digging Depth: ~6.5 m (with standard arm)
Max Reach at Ground Level: ~9.8 m
Max Dumping Height: ~6.7 m
Swing Speed: 12 rpm
Travel Speed: 5.2 km/h (high), 3.3 km/h (low)
Gradeability: 35° (70%)
4. Hydraulic System
Main Pump Type: Variable displacement axial piston pump (x2)
Flow Rate: 2 × 200 L/min (total ~400 L/min)
System Pressure: 34.3 MPa
Pilot Pressure: 3.9 MPa
Hydraulic Circuit: Load-sensing system (LSS)
5. Dimensions
Transport Length: ~9.5 m
Transport Width: ~2.8 m
Transport Height: ~3.0 m (cab top)
Undercarriage Width: 600 mm (standard shoe)
Track Gauge: 2,380 mm
